Heating with renewable energy from the environment – even in the higher output ranges
Natural heat is an advanced and cost effective alternative to fossil fuels. It is available free of charge and offers independence from oil and gas.
Heat pumps offer ideal conditions for reducing heating bills and achieving environmentally responsible heat generation. After all, the energy a heat pump uses is free and available in unlimited supply from the environment.
With a heat pump, up to 80 percent of the total energy demand can be drawn from nature in a highly effective and environmentally responsible manner. Only 20 to 30 percent electrical energy needs to be invested.
The principle is as simple as it is ingenious: the solar energy stored in the ambient air, ground and groundwater is used to efficiently heat domestic hot water and heating water.
Added value through cooling function and dual mode systems
Heat pumps are also available with high outputs and are designed to meet the energy demand of larger residential complexes and commercial operations. The operating mode can be „reversed“, allowing the heat pump to be used for cooling in summer too. The idea that a heat pump only suits new build projects is outdated. On the contrary, if an existing conventional oil or gas heating system is modernised or supplemented with a heat pump (to form a dual mode system), significant reductions in heating costs can be achieved and emissions lowered at the same time. Independence from fossil fuels actively contributes to reducing CO2 emissions and protecting the climate.
Recovering environmental energy
Various natural sources are suited to heat recovery using a heat pump:
- Water – such as groundwater, river or lake water, waste water
- Ground – via geothermal probes, geothermal collectors, energy piles
- Waste heat
Not all of these heat sources can be used in all locations. It is therefore necessary to
consult the relevant authorities before making a decision, and discuss the technical options with Viessmann.
Vitocal 300-G/-W Pro
Efficient solutions for professional applications
The Vitocal 300-G Pro is a large heat pump for larger apartment buildings as well as commercial and municipal applications, with five output ratings to enable most requirements to be reliably met up to 1200 kW.
Vitocal 350-HT Pro
High temperature heat pump for utilisation of waste heat in renewable heat
for the commercial sector. The use of renewable heat in commercial
applications is determined by the need for high flow temperatures. The new
Vitocal 350-HT Pro heat pump extends the comprehensive product range from
Vitocal 300-G/-W Pro
The Pro series of the Vitocal 300-G Pro heat pumps features all the characteristics of the highly efficient Vitocal 300-G series.
The five output ratings enable most requirements from residential and commercial buildings to be reliably met.
These appliances are standardised, enabling quick and comprehensive engineering, as well as transparent cost calculation.
Space efficient design
Just 88 centimetres wide, the Vitocal 300-G Pro can be handled easily to its installation site using the lifting clearance integrated into its base. For higher outputs, up to five units can be connected in a cascade.
Optimised appliance construction for quiet operation
As is the case for all heat pumps, the compressors emit noise in the 50 to 60 Hz range. Due to the high quality construction of the frame and anti-vibration casing components, it has been possible to keep this noise within the casing.
Vibrations on the base support are barely perceptible as the 3-D antivibration construction is specifically designed to dissipate oscillations. With sound power levels of, for instance, 65 dB (A) for the 197 kW heat pump, its values stand up well by comparison with other products in this market segment.
Pre-assembled electrical equipment
Proven and reliable technology
Vitocal 350-HT Pro
Heat pump with flow temperatures up to 90 °C
As a heat pump from standard production, the Vitocal 350-HT Pro series delivers flow temperatures up to 90 °C and utilises heat source temperatures up to 50 °C. This makes it particularly suitable for the utilisation of waste heat and for the generation of high temperatures for industrial and commercial processes, or for older local heating networks.
Remote monitoring and communication
In addition, the control unit features many communication options. LAN-supported systems as well as Modbus and BACnet interfaces can be used. These make the system accessible for remote monitoring and integration into building management systems. The 5.7 inch colour touchscreen offers intuitive operation and easy control.
New refrigerant meets more stringent requirements
The use of the new HFO refrigerant, R1234ze, means that this series of appliances already meets the refrigerant regulations set for 2020 and beyond. The GWP (global warming potential) is in the single-figure range and is therefore almost as low as that of natural refrigerants.
At Precision Heating we can offer the following;
System design assistance Full technical support
Specification assistance CAD & BIM Library
CPD Presentations Product commissioning
Need more information on this product, download our guides for more technical information.
Request a call back from one of our engineers.
