Up to 98% of the fuel used is converted into heat- Quiet operation thanks to low fan speed
- Compact dimensions, only 450 mm wide
- Easy to operate Vitotronic control unit with 7 inch colour touchscreen
- Integrated WiFi interface for internet connection
- Energy efficiency class: A
- Optionally available as combi or system boiler
- Convenient operation at eye-level through upwards movable display
- New environmentally responsible MatriX-Plus burneraz
- Modulation range 1:17
Key Benefits
Vitodens 200-W is ideal for detached houses and larger homes
Compact and efficient wall-mounted gas condensing boilers with exemplary price/performance ratio and high heating and DHW convenience.
The Vitodens 200-W is the ideal wall-mounted gas condensing boiler for detached houses and properties with 4+ bedrooms. It can be easily installed in a recess in the bathroom or in a kitchen cabinet. The Vitodens 200-W is equipped with an Inox-Radial heat exchanger made of high-grade stainless steel. It guarantees reliability and permanently high condensing efficiency. This also applies to the MatriX-Plus burner.
The wall-mounted gas condensing boilers consume less energy because they additionally utilise the heat in the flue gas. The result: a high rate of conversion of spent energy to heat of up to 94 percent and energy efficiency class A. This reduces heating costs and protects the environment.
Seamless integration with other heating systems
The next higher class of A+ is achieved if the boiler is combined with solar thermal collectors.
Vitodens 200-W available as a system boiler and combi boiler
The Vitodens 200-W is optionally available as a system boiler with separate DHW supply or as a combi boiler with an integral instantaneous water heater.
Special features of the Vitodens 200-W
Movable display for convenient eye-level operation
The Vitodens 200-W can be conveniently operated at eye level thanks to the repositionable 7 inch LED colour touchscreen display .
H₂ 20% blend all set for climate-neutral heating with gas
Viessmann’s advanced gas condensing boilers are H2-ready. This means they are designed for natural gas with an admixture of up to 20 % hydrogen (H₂). From 2025, you will even be able to operate condensing boilers on 100 % hydrogen. This means that you already have an appliance that is ready for future changes in the gas supply without any major modifications being required. The patented Lambda Pro Plus® combustion controller automatically adjusts to the respective fuel.
Available as a system or combi boiler
The corrosion-resistant stainless steel Inox-Radial heat exchanger with unrivalled wall thickness, is extremely durable and achieves efficiency levels of up to 98%. The boiler’s special design ensures the very low operating noise of 39 dB(A) maximum (26 kW), which is perfectly acceptable even in the kitchen.
Lambda Pro Plus: automatic combustion control cuts costs
Viessmann’s modern gas condensing boilers are equipped with the patented Lambda Pro Plus® combustion control system. It adapts your appliance to changing operating conditions such as fluctuating gas qualities or different gas types. The automatic control ensures a consistently high level of efficiency for your system. Your contractor does not have to readjust these boilers, and flue gas inspection intervals are extended to three years.
Automatic monitoring of combustion quality compensates for fluctuating gas qualities and extends the flue gas inspection intervals to three years. This ensures consistently high efficiency and saves on maintenance costs.
- Matching to gas quality
- Consistently high energy efficiency
- Futureproof
- Low maintenance costs
- Three year inspection intervals
The MatriX-Plus burner: the heart of your heating system
Among the outstanding benefits of the new MatriX-Plus burner are its efficient operation, quiet running and low emissions. The special stainless steel MatriX surface is resistant to high temperatures, which ensures reliable performance and a long service life.
Stainless steel Inox-Radial: efficient and durable
Stainless steel makes all the difference. The corrosion-resistant stainless steel Inox-Radial heat exchanger is at the heart of the Vitodens 200-W. It converts the consumed energy into heat very efficiently. Almost no losses, with practically unbeatable efficiency of 98 percent. In addition, the particularly durable, high grade stainless steel ensures reliability.
Clear and intuitive controls
Simple operation with 7-segment display
The LED screen with 7-segment display of the new Viessmann One Base platform features a discreet “black panel” visual design and is noted for its simple, easy to understand operation. It can be used for convenient control of heating systems with a direct heating circuit and/or a heating circuit with mixer.
Integral WiFi interface: heating convenience goes digital
The Vitodens 200-W can be operated easily and intuitively from a smartphone and tablet via the integral WiFi interface, or directly from the 7 inch colour touchscreen. By selecting this boiler, the user will also benefit from low maintenance costs: All components are accessible from the front, no side clearance for servicing is required. When controlling the Vitodens 200-W via the ViCare app, a Viessmann Trained Installer can automatically be notified in the event of a fault.
Product Details
Output in kW
ERP Efficiency
Fuel
Application area
Operation
DHW heating
Additional features
2.5 to 32 kW
94% (Class A)
Natural gas and LPG, certified for the combustion of natural gas with 20 % hydrogen (H₂) content
Gas heating in detached houses, 4+ bedroom homes | New build and modernisation projects
Excellent ease of use with the 7 inch display, Vitotrol remote control units or via the ViCare app; integral WiFi interface for internet connection.
An additional DHW cylinder is required for the gas condensing system boiler. The combi boiler has an integral instantaneous water heater.
MatriX-Plus burner, Lambda Pro Plus automatic combustion controller
