• Maximum efficiency for new build and modernisation projects in detached houses and apartment buildings
  • Ground source heat pump: heating outputs, single stage: 5.7 to 17.2 kW, two-stage: 11.4 to 34.4 kW
  • Water/water heat pump: heating outputs, single stage: 7.5 to 22.6 kW, two-stage: 15 to 45.2 kW
  • Vitocal 300-G: with integral high efficiency pump for brine and heating circuits, plus circulation pump for cylinder heating, safety assembly with safety valve, pressure gauge and air vent valve (for type BWC)
  • Maximum flow temperature up to 65°C
  • Vitotronic 200 control unit with energy statement

Key Benefits

  • Compact dimensions and small footprint to maximise available space in the building
  • High efficiency all year round at any operating point through innovative RCD system with electronic expansion valve
  • Low noise and vibration levels thanks to sound-optimised appliance design – sound power level ≤ 42 dB(A)
  • Prepared for Smart Grid and utilisation of PV power generated on site
  • Master/slave solutions for very high flexibility, such as a Vitocal 300-G and 350-G combination
  • Low running costs thanks to a high COP (coefficient of performance) to EN 14511 of up to 5.0 (brine 0°C/water 35°C) and integral high efficiency pumps (for Vitocal 300-G, type BWC)

Key Benefits

  • Maximum efficiency for new build and modernisation projects in detached houses and apartment buildings
  • Ground source heat pump: heating outputs, single stage: 5.7 to 17.2 kW, two-stage: 11.4 to 34.4 kW
  • Water/water heat pump: heating outputs, single stage: 7.5 to 22.6 kW, two-stage: 15 to 45.2 kW
  • Vitocal 300-G: with integral high efficiency pump for brine and heating circuits, plus circulation pump for cylinder heating, safety assembly with safety valve, pressure gauge and air vent valve (for type BWC)
  • Maximum flow temperature up to 65°C
  • Vitotronic 200 control unit with energy statement
  • Compact dimensions and small footprint to maximise available space in the building
  • High efficiency all year round at any operating point through innovative RCD system with electronic expansion valve
  • Low noise and vibration levels thanks to sound-optimised appliance design – sound power level ≤ 42 dB(A)
  • Prepared for Smart Grid and utilisation of PV power generated on site
  • Master/slave solutions for very high flexibility, such as a Vitocal 300-G and 350-G combination
  • Low running costs thanks to a high COP (coefficient of performance) to EN 14511 of up to 5.0 (brine 0°C/water 35°C) and integral high efficiency pumps (for Vitocal 300-G, type BWC)

vitocal-300-g-heatpump
Vitocal 300-G heat pump

As a ground source heat pump, the Vitocal 300-G draws thermal energy from highly efficient heat sources. For this, a geothermal probe, an ice store system or a geothermal collector is installed on the property. In all these cases, the heat pump covers the entire energy demand, even on colder days. As an alternative, depending on the location of the house, it may also be possible to utilise the thermal energy contained in the groundwater. In this case, the Vitocal 300-G is simply configured for operation as a water/water heat pump. It can be used for new build and modernisation in detached houses and apartment buildings.

Vitocal 300-G heat pump

As a ground source heat pump, the Vitocal 300-G draws thermal energy from highly efficient heat sources. For this, a geothermal probe, an ice store system or a geothermal collector is installed on the property. In all these cases, the heat pump covers the entire energy demand, even on colder days.

As an alternative, depending on the location of the house, it may also be possible to utilise the thermal energy contained in the groundwater. In this case, the Vitocal 300-G is simply configured for operation as a water/water heat pump. It can be used for new build and modernisation in detached houses and apartment buildings.

vitocal-300-g-heatpump
EHPA seal of approval

The EHPA seal of approval serves as proof of the COP (Coefficient of Performance) for the heat pump according to the market incentive program. The German EHPA quality seal commission certifies that the Viessmann  Vitocal 300-G heat pump meets the requirements of the EHPA quality seal regulations.

ehpa APPROVED HEAT PUMP
EHPA seal of approval

The EHPA seal of approval serves as proof of the COP (Coefficient of Performance) for the heat pump according to the market incentive program. The German EHPA quality seal commission certifies that the Viessmann  Vitocal 300-G heat pump meets the requirements of the EHPA quality seal regulations.

ehpa APPROVED HEAT PUMP
Vitotronic_Heating-curve
Operating convenience

Clear, comfortable, intelligent: The Vitotronic offers perfect functions for fast and exact control of every heating system. Control Vitotronic 200 – Can also be operated using an app via a smartphone at any time.

Operating convenience

Clear, comfortable, intelligent: The Vitotronic offers perfect functions for fast and exact control of every heating system. Control Vitotronic 200 – Can also be operated using an app via a smartphone at any time.

Vitotronic_Heating-curve
Vitoconnect 100 creates the connection

The Vitoconnect 100 interface is required for operation via the app. Retrofitting earlier heat pumps of the Vitocal series (from year of construction 2010) is possible at any time.

Vitoconnect_Anschluesse
Vitoconnect 100 creates the connection

The Vitoconnect 100 interface is required for operation via the app. Retrofitting earlier heat pumps of the Vitocal series (from year of construction 2010) is possible at any time.

Vitoconnect_Anschluesse
A perfect match – System technology

“The whole is greater than the sum of its parts”. Following this philosophy, Viessmann supplies more than high quality, reliable and effective heating components. In fact, all products are part of a matching total concept, where all components complement one another. After all, only perfect interaction between all system components can draw out the maximum potential of our innovative leading technology.

Viessmann system technology incorporates everything you need for a reliable and economical heating system: From the Vitotronic control unit with wireless remote control, powerful Vitocell DHW cylinders for the highest DHW convenience, right up to high grade solar thermal systems for cost effective central heating backup.

High output and quiet operation

The powerful Compliant scroll compressor fitted in the Vitocal 300-G heat pump is outstanding on account of its high operational safety, reliability and especially quiet operation. Essentially, this is due to the double sound insulation measures that include anti-vibration mounts to prevent structure-borne noise and insulation of the casing against airborne noise. At the same time, the compressor guarantees the highest coefficient of performance (COP up to 5.0) and flow temperatures up to 65°C.

The Refrigerant Cycle Diagnostic (RCD) system constantly monitors the refrigerant circuit in the Vitocal 300-G and, in conjunction with the electronic expansion valve, ensures the highest efficiency at any operating point, which results in high seasonal performance factors.

Modular solution for higher heat demand

For residential buildings with a higher heat demand, the two-stage Vitocal 300-G based on the master/slave principle is the right choice. It can also be configured for the ground or groundwater as the heat source. For this purpose, two heat pumps are linked together. This delivers the high heating output required and increases the operational reliability of the entire system. The modular layout, with separate compressor circuits, also ensures particularly high levels of efficiency in partial load operation, and enables the simultaneous operation of central and DHW heating.

With five output stages as a master or master/slave version, various combinations can be realised and matched to the required heat demand. Because of this flexibility, systems can be configured so that runtimes match demand, thus ensuring economical operation. The master module regulates the slave module. Furthermore, the entire system can be equipped with high efficiency pumps.
