    Bentone Burners

    Precision Heating Ltd > Bentone Burners
    bentone burners

    Bentone Burners

    Oil and RME (rapeseed oil) burners



    All over the world our oil burners are known for their reliability, efficiency and performance.

    Bentone is leading the way with new development within combustion engineering and we are working continuously to reduce CO2 emissions. We focus on quality, high performance and low fuel consumption and all our burners carry the CE marking and are produced according to the European norm EN 267.

    We started as a small scale operation with our own developed oil burner and within 10 years we exported our oil burners to major parts of Europe but also to the Middle East. Our success from the start was our high quality and low fuel consumption and we have continued to focus on our winning concept.

    Approved burner for industrial applications

    In addition our oil burners can be delivered approved according to the EN 267 J and K Directive. (Applicable in the EU and countries that comply with the same standard)

    Annex J – Harmonization of the Machinery Directive:
    Requirements for installation of burners in industrial applications. For example. ovens, hot air boilers, melting furnaces and spray booths.

    EN 746-2 – Industrial process burners:
    Requirements for the installation of burners on boilers for processing, refining, industrial ovens, manufacturing and other industrial processes.

    Annex K – Harmonization of the Pressure Vessel Directive:
    Requirements for the installation of burners on boilers, hot water boilers and hot oil boilers with a temperature above 110 ° C.

    Bentone B30

    B30 is an industrial burner designed for industrial applications but can also be used for heating in commercial buildings.

    Capacity: 4,5-17 kg/h (55-200 kW)

    The burners exist as 1-stage or 2-stage versions.

    The 1-stage burner has 1 nozzle for On/Off control and the 2-stage burner has 1 nozzle and working pressure on the oil which is controlled by a solenoid valve in the oil pump.

    Hydraulic adjustment of the nozzle assembly is optional on the 2-stage models.

    Brochure

    Download Brochures

    Models

    ModelArt. No.Information
    B30A510005051601Capacity: 6-17 kg/h (72-200 kW)
    Bentone B30 2A 1F 230V520003752601Capacity: 6-17 kg/h (72-200 kW)
    Bentone B30 A2.2H 1F 230V520003952602Capacity: 4,5-15 kg/h (55-175 kW)
    Bentone BF30 MF LP14-36-41396

    Advantages

    • Energy saving and compatible with environmental requirements
    • Quiet in operation and designed for easy maintenance
    • Reliable and trouble free
    • Designed and approved in accordance with the European standard EN 267
    • Suitable for High Resistance Boilers
    • Industry standard components easily available
    • Available with hydraulic air adjustment or airdamper motor
    • Plug-in contact facilitates the installation
    • Low fuel consumption
    • Available in several standard models, including burners approved for RME
    • Available according to Annex J & K

    Bentone B40

    B40 is an industrial burner designed for industrial applications but can also be used for heating in commercial buildings.

    Capacity: 8-29,5 kg/h (95-350 kW)

    The burners exist as 1-stage or 2-stage versions.

    The 1-stage burner has 1 nozzle for On/Off control and the 2-stage burner has 1 nozzle and working pressure on the oil which is controlled by a solenoid valve in the oil pump.

    Hydraulic adjustment of the nozzle assembly is optional on the 2-stage models.

    Models

    ModelArt. No.Information
    B40A530005153601Capacity: 9-29,5 kg/h (107-350 kW)
    Bentone B40 2A540004554004Capacity: 9-29,5 kg/h (107-350 kW)

    Advantages

    • Energy saving and compatible with environmental requirements
    • Quiet in operation and designed for easy maintenance
    • Reliable and trouble free
    • Designed and approved in accordance with the European standard EN 267
    • Suitable for High Resistance Boilers
    • Industry standard components easily available
    • Available with hydraulic air adjustment
    • Plug-in contact facilitates the installation
    • Low fuel consumption
    • Available in several standard models, including burners approved for RME
    • Available according to Annex J & K

    Brochure

    Download Brochures

    Bentone BF1

    BF1 is our most flexible burner for domestic applications and exists in several versions. Designed for modern effective combustion and Ecodesigned approved according to class 3.

    Capacity: 0,9-7,6 kg/h (11-90 kW)

    BF1 can be used for traditional heating of domestic and commercial buildings including industrial applications and mobile equipment.

    The burner has small dimensions and a high capacity and parts are easy to replace which makes the burner very service friendly. The burner is delivered as a complete unit with fittings and maintenance instructions.

    Models

    ModelArt. No.Information
    Bentone BF1 FU351012010601Capacity: 1,3-4,6 kg/h (15-55 kW)
    Bentone BF1 FUV352012020601Capacity: 1,3-4,6 kg/h (15-55 kW)
    Bentone BF1 FUV HC352012021601Capacity: 1,3-4,6 kg/h (15-55 kW)
    Bentone BF1 FUV RME352012044601Capacity: 1,4-7,9 kg/h (14,5-81,6 kW)
    Bentone BF1 KV RME352043024601Capacity: 3,5-8,6 kg/h (41,8-102,7 kW)

    Advantages

    • Energy saving and compatible with environmental requirements
    • Designed for easy regulation and maintenance
    • Reliable and trouble free
    • Designed and approved in accordance with the European standard EN 267
    • Suitable for High Resistance/ Condensing boiler
    • Industry standard components easily available
    • Plug-in contact facilitates the installation
    • Available in several standard models, including burners approved for RME

    Brochure

    Download Brochures

    Bentone & Turco

    With over 40 years industry experience,Precision Heating LTD is one of Ireland’s leading supplier of the most complete and innovative range of Boilers. Our products range from oil condensing boilers to LPG/Nat Gas boilers. We provide technical after sales assistance for every boiler.

    Our Boilers are made with stainless steel plate heat ex-changer’s. We offer both commercial and domestic ranges of boilers. Whether you are looking to fit out a house , church , office building or school. We have a portfolio of products that are widely suitable and adaptable to each project.
