Oil and Gas Boilers up to 2 MW

Proven Viessmann quality up to 2000 kW for oil and gas with high standard seasonal efficiency [to DIN].

The comprehensive range from Viessmann covers every demand for innovative heating technology. Here, you can find the exact solution to suit your needs with regard to building services, convenience and budgetary constraints.

The versatility of the Vitoplex range, which in terms of technology and price is divided into the 300 and 200 categories, ensures that the perfect solution is available for every demand and budget. One thing that all products share is the top quality for which Viessmann is renowned.

The Vitorond 200 comes into its own where the boiler needs to be installed under demanding spatial conditions.

The Vitoplex 300 three-pass boiler, with its proven multi layered
convection heating surfaces, offers particularly economical, clean and
reliable operation. Multi-layered convection heating surfaces made from
triplex pipes The multi layered convection heating surfaces of the Vitoplex 300 comprise telescopic steel pipes pressed into each other for heat transfer. The innerpipe, surrounded by folded linear fins, provides a heating surface 2.5 times greater than that of smooth pipes. Heat transfer occurs proportionately
due to the different gaps between the press points, so the back area of
the triplex pipes transfers less heat to the boiler water, as the combustion
gases circulating here are no longer quite as hot. This way, the surface
temperature remains above the dew point, the formation of condensate is
counteracted and corrosion damage is prevented.

The compact Vitoplex 200 steel boiler is available from 440 to 1950 kW. Over
its entire output range, this three-pass boiler offers the right conditions for
environmentally responsible and clean combustion. A wide range of burners
can be easily adapted for use with this boiler. The Vitoplex 200 is a three-pass boiler with low combustion chamber loading. Consequently, it delivers clean combustion with particularly low nitrogen oxide emissions.
Optimum combustion and low emission Pressure-jet oil/gas burners from
ELCO and Weishaupt are already fully adjusted and wired for the full
output range. This ensures optimum combustion with low emissions.

Therm-Control saves installation time and costs No minimum heating water flow rate is required because of the wide water galleries. This simplifies the hydraulic connection. Therm-Control in the output range from 440 to 560 kW also makes return temperature raising facilities superfluous. This saves installation time and additional outlay.
